X61-I
- Alder Lake is Intel’s 12th-gen Core i3-N305 processor
- DDR4 SODIMM Slot
- OS supported: Windows 10/11 loT, Linux as per request
- Fanless box PC for harsh Retail/Industrial application.
| Specification | X-61-I |
|---|---|
| Processor | Intel 12th Gen Alder Lake-N Core i3-N305 Processor |
| Speed / Core | 3.8 GHz Turbo Frequency / 8 Cores |
| Memory | DDR4 SODIMM Slot up to 32GB |
| Slots | 1 X 10/100/1000 (RTL8111H) |
| Storage | Dual Storage of M.2 (B Key, 2280) Slot for SSD |
| I/O & Expansion | |
| USB | 8 USB |
| Serial | 2x RS232 (COM 2 support RS232/RS485 switch) |
| VGA | N/A |
| HDMI | 2 |
| LAN | 2 - Support PXE (RTL8111H) |
| Expansion for Wi-Fi (optional) | One M.2 slot (E Key, 3052 for WiFi/BLE Module 802.11b/g/n/ac/ax (1 x PCIe, 1 x USB2.0) |
| Physical Dimension | |
| Dimension | 123mm X 150mm X 32mm (L X W X H) |
| Weight (N. W.) | 2 kg |
| Environmental | |
| Operating Condition | -10°C ~ 50°C |
| Power In | 12V DC, DC Jack |
